Electric Chain Hoist With Trolley
-
Type: Suspension or trolley running
-
Usage: Material handling, metallurgy, mining, oil, petrochemical, etc
-
Sling Type: Wire rope
-
Maximum Lifting Weight: 10t
-
Maximum Lifting Height: 120m for small capacity
-
Lift Speed: 1~7.6m/min
-
Power Source: 3P, 380V, 50HZ, other type also available
-
Controler: Pendent control, remote control
-
Certification: ISO9001:2008, CE
Electric Chain Hoist, PK Chain Block, Electric Chain Hoist with Mature Technology.
Detailed Product Description
Nante PK chain hoists tolerate large loads with ease and require little maintenance. They provide more allowance for side pulling, and provide true vertical lift at no extra cost.
PK electric chain hoist is a starting weight of 125-3000kg of equipment to upgrade and run with a small size, light weight, flexible operation, and other advantages.
PK electric chain hoist is a mature technology products, the use of safe, good quality, long life, high efficiency, widely used in industry, commerce, service industries and handicraft enterprises in a variety of places, is to improve the work efficiency and improve labor conditions for equipment. The hoist is designed according to the principle of self-designed cone-shaped brake rotor motor, general speed, and with precision lifting under all forms of speed. In the direct gear reducer, the second-gear drive installed on the insurance even friction axis, so that the chain electric hoist suffer from extreme overload, wear-resistant high-strength steel chain to enhance security and stability. As a result, security is of great reliability.
Application
Whether chain hoist or wire rope hoist, electric or pneumatic; our line of powered hoists are ideal in manufacturing, power generation, and industrial facilities where heavy items are lifted and positioned as part of production or warehousing. Our new model high-capacity wire rope hoist complements our line with capacities up to 50 Tons. We offer a full line of manual hoists, both hand chain and lever tools, which are used primarily for maintenance and construction activities.
Design features:
-
Safe usage, reliable quality, long service life.
-
The running rail can be I beam, as well as flexible crane standard track.
-
There are two operation option for the pendent control.
-
High efficient energy-saving motor, efficient brake system.
-
Light weight, compact.
Technical Parameters
|
Model
|
PK1
|
PK2
|
PK5
|
PK10
|
|
PK1N-1F
|
PK1N-2F
|
PK2N-1F
|
PK2N-2F
|
PK5N-1F
|
PK1N-2F
|
PK10N-1F
|
PK10N-2F
|
|
Capacity
|
125
|
225
|
250
|
500
|
500
|
1000
|
1000
|
2000
|
|
No.of load chain fall lines
|
1
|
2
|
1
|
2
|
1
|
2
|
1
|
2
|
|
Lifting Height
|
3
|
|
Lifting Speed
|
8
|
4
|
10
|
5
|
10
|
5
|
8
|
4
|
|
2
|
1
|
2.5
|
1.25
|
2.5
|
1.25
|
2
|
4
|
|
Lifting Motor Power
|
0.2
|
0.5
|
1
|
1.5
|
|
0.05
|
0.13
|
0.25
|
0.35
|
|
Voltage
|
3-380V 50HZ
|
|
Rating
|
40/20
|
|
Load Chain Dia x Pitch
|
4x12
|
5x15
|
7x21
|
10x28
|
|
Hoist Weight at 3 Meters Lifting Height
|
16
|
17
|
32
|
34
|
48
|
53
|
68
|
80
|
|
Electracally operated movement car
|
Model
|
EU5PK
|
EU10PK
|
|
Running Speed
|
14/28
|
|
Motor Power
|
0.14/0.2
|
|
Rating
|
40
|
|
I Beam Model
|
12--28b
|
18--56b
|
|
Smallest Curve Radius
|
1.0/1.4
|
1.6/2.0
|
|
The hand pulls
|
Model
|
RU1PK
|
RU2PK
|
RU5PK
|
RU10PK
|
|
the car
|
I Beam Model
|
10--16
|
12.6--28b
|
12.6--28b
|
18--56c
|
|
|
Smallest Curve Radius
|
0.5--0.8
|
1.0--1.4
|
1.6--2.0
|
