LED Display 1t - 30t Crane Hook , High Strength Load Receptor Crane Scale

Name: LED Display 1t 30t Crane Hook High Strength Load Receptor Crane Scale
Brand: Nante
Price: 1 USD

Place of Origin : Zhejiang, China

Brand Name : Nante

Certification : ISO9001, CE

Model Number : HD

MOQ : 1pc

Price : N/A

Packaging Details : Seaworthy packing

Delivery Time : Within 14 days

Payment Terms : T/T, L/C

Supply Ability : 10000pcs per year

Contact Now

LED Display 1t - 30t Crane Hook , High Strength Load Receptor Crane Scale

Quick Details

Place of Origin: Zhejiang, China (Mainland)
Brand Name: NANTE
Model Number: OCS-G
Type: Crane Scale
Power Supply: Battery
Display Type: LED display
Rated Load: 1t~30t
Accuracy: Digital Calibration
Capacity: 1t~30t

Introduction

Crane scales are used to measure the weight of a load as it is lifted, typically by a crane, hoist or winch.

From material handling, to proof testing and controlled tensioning, we offer a wide selection of crane scales for sale with features and capacities to meet a large variety of your weighing needs like peak hold and battery power.

Our crane scale weighs up to 1000 pounds in 0.5 pound intervals. A higher capacity is also available.

Specifications

American standard eye hook
American standard bow shackle
2*rechargeable batteries

Parameters

Size and weight
Max.Cap	A	B	C	L	N.W
(t)	mm	mm	mm	mm	(kg)
1t	55	65	35	420	35kg
2t	72	80	45	600	35kg
3t	92	100	55	730	45kg
5t	98	120	70	850	58kg
10t	130	140	80	900	88kg
15t	150	160	80	950	92kg
20t	165	180	90	1120	175kg
30t	220	380	105	1350	450kg

Specification
Accuracy class	OIML III
Tare range	100%F.S.
Zero range	4%F.S.
Safe overload	120%F.S.
Ultimate overload	500%F.S.
Overload alarm	100%F.S.+9e
Battery	6V/10Ah
Adaptor	DC9V
Radio frequency	450MHZ
Radio distance	>100m

Safe distance
Temperature	Safe distance
1000°C	1.2m
1200°C	1.5m
1400°C	1.8m
1600°C	2.0m

Functions
Zero	Tare
Date/time	Overload alarm
Tare/set	Batter supervision
Acc/del/view	Resolution switch
Digital calibration

Features

High-strength load receptor

Steel chrome plated case

American standard bow shackle

American standard eye hook

2*rechargeable batteries

Optional indicators

Capacity:1t~30t

Diagram
